Yamaha 115HP Outboard

Remote Control | Electric Start | Power Trim and Tilt | 176kg

Famous for their incredible torque, our V MAX engines also show a quiet side: we have harmonised all the inertial mass components and added large rubber engine mounts for a whole new level of smooth!

The use of lightweight, mounting brackets, power trim and tilt mechanism and composite body parts – with a state-of-the-art compact engine layout, means the new V MAX SHO 115hp transforms the feel, handling and performance of any boat.

Yamaha 115HP Outboard

Engine Specifications:

• Engine type: 4-stroke
• Displacement: 1832 cm³
• No. of cylinders/configuration: 4/In-line, 16-valve, DOHC
• Bore x stroke: 81.0 mm x 88.9 mm
• Prop shaft output at mid range: 84.6kW / 115hp
• Full throttle operating range: 5,300 – 6,300 rpm
• Lubrication system: Wet sump
• Fuel Induction System: EFI
• Ignition / advance system: TCI
• Gear ratio: 2.15 (28/13)

Dimensions:

• Recommended boat transom height: L 516 mm
• Weight with propeller: 176 kg
• Oil pan capacity: 3.2 litres

Features:

• Control: Remote control
• Starting Method: Electric Start
• Trim and tilt method: Power trim and tilt
• Battery Charging:12v – 35A Output
• Propeller: Included

Rigging Options Available – See Our “Yamaha Outboard Control Box and Rigging Kits”
